ASUS PRIME A520M-R Bundkort - AMD A520 - AMD AM4 socket - DDR4 RAM - Micro-ATX
Bundkort, størrelse: Micro-ATX, AMD AM4 socket, AMD A520 chipset, 1 x PCI-Express 3.0 x16, Dual DDR4-3200 2 x DIMM slots, lagrings tilslutninger: 4 x SATA-600 / 1 x M.2 NVMe PCI-Express 3.0 (M.2 size: 2242 / 2260 / 2280), USB 3.2 Gen 1 type A, skærm tilslutning: 1 x HDMI 2.1, Realtek 1 Gigabit netværk (LAN), AMD Graphics supporteret (CPU med VGA påkrævet), Realtek HD Audio (8-kanaler)
454,00 kr.
363,20 kr. ekskl. moms
Billigste fragt (privatkunde) 33,00 kr.
Fjernlager, 5-6 dages levering
The ASUS PRIME A520M-R motherboard provides a reliable foundation for building high-performance PCs, suitable for gamers, creators, and professionals. It supports a broad spectrum of Ryzen processors, from the 3000 Series to the 5000 G-Series, offering users the flexibility to select the ideal CPU for their requirements. With high definition 8-channel audio, it offers an exceptional sound experience, enhancing games, movies, and music. The motherboard's support for DDR4 memory up to 5100 MHz (O.C.) ensures smooth and responsive performance, perfect for multitasking and demanding applications. Connectivity is straightforward, with a variety of ports including USB 3.2 Gen 1 and HDMI, making it easy to connect to a wide range of devices. Constructed with ASUS 5X Protection III, including overvoltage protection and a stainless steel back I/O, the PRIME A520M-R is built for durability and long-term reliability, representing a wise choice for anyone looking to build a powerful, future-proof PC.
Producent
Varenummer
3238116
Model
90MB1H60-M0EAY0
Ean
4711387466414
Til producentens hjemmeside
Produktbeskrivelse
ASUS PRIME A520M-R - bundkort - micro-ATX - Socket AM4 - AMD A520
Produkttype
Bundkort - micro-ATX
Chipsættype
AMD A520
Processor-socket
1 x Socket AM4
Kompatible processorer
Ryzen (understøtter Ryzen 3000 Series/ 3000 G-Series/ 4000 G-Series/ 5000 Series/ 5000 G-Series)
Max RAM-størrelse
64 GB
RAM understøttet
2 DIMM slots - DDR4, ECC, ikke bufferet
Lagringsporte
4 x SATA-600 (RAID), 1 x M.2
USB / FireWire porte
4 x USB 3.2 Gen 1 + 2 x USB 2.0 + (2 x USB 3.2 Gen 1 + 4 x USB 2.0 via samlekasser)
Audio
HD Audio (8-kanaler)
LAN
Gigabit Ethernet
Generelt
Produkttype
Bundkort - micro-ATX
Chipsættype
AMD A520
Processor-socket
Socket AM4
Max antal processorer
1
Kompatible processorer
Ryzen (understøtter Ryzen 3000 Series/ 3000 G-Series/ 4000 G-Series/ 5000 Series/ 5000 G-Series)
Understøttet RAM
Maks. størrelse
64 GB
Teknologi
DDR4
Bus Clock
2400 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 2933 MHz, 3400 MHz (O.C.), 3333 MHz (O.C.), 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 4200 MHz (O.C.), 4333 MHz (O.C.), 4600 MHz (O.C.), 3200 MHz, 4866 MHz (O.C.), 4466 MHz (O.C.), 5100 MHz (O.C.)
Understøttet RAM-integritetskon
ECC
Registreret eller buffer
Ikke bufferet
Egenskaber
Dobbelt kanal hukommelses arkitektur
Audio
Type
HD Audio (8-kanaler)
Overensstemmelsesstandarder
High Definition Audio
LAN
Netværks interfaces
Gigabit Ethernet
Ekspansion / Konnektivitet
Ekspansionsåbninger
1 x CPU
2 x DIMM 288-pins
1 x PCIe 3.0 x16
1 x PCIe 3.0 x1
1 x M.2 socket (2242/2260/2280 M.2 Key M åbning)
2 x DIMM 288-pins
1 x PCIe 3.0 x16
1 x PCIe 3.0 x1
1 x M.2 socket (2242/2260/2280 M.2 Key M åbning)
Grænseflade (lagring)
SATA-600 -stikforbindelser: 4 x 7pin Seriel ATA - RAID 0 / RAID 1 / RAID 10
SATA-600 / PCIe 3.0 -stikforbindelser: 1 x M.2
SATA-600 / PCIe 3.0 -stikforbindelser: 1 x M.2
Interface
4 x USB 3.2 Gen 1
2 x USB 2.0
1 x HDMI
1 x LAN (Gigabit Ethernet)
1 x PS/2-tastatur
1 x PS/2-mus
1 x mikrofon - mini-jack
1 x audio linje-ind - mini-jack
1 x audio linje-ud - mini-jack
2 x USB 2.0
1 x HDMI
1 x LAN (Gigabit Ethernet)
1 x PS/2-tastatur
1 x PS/2-mus
1 x mikrofon - mini-jack
1 x audio linje-ind - mini-jack
1 x audio linje-ud - mini-jack
Interne interfaces
2 x USB 3.2 Gen 1 - intern stik
4 x USB 2.0 - intern stik
1 x SPI - intern stik
1 x SPDIF ud - intern stik
1 x audio - intern stik
1 x seriel - intern stik
1 x højttaler - intern stik
4 x USB 2.0 - intern stik
1 x SPI - intern stik
1 x SPDIF ud - intern stik
1 x audio - intern stik
1 x seriel - intern stik
1 x højttaler - intern stik
Strømkontakter
4-pin ATX12V konnektor, 24-pin hovedstrøm-konnektor
Egenskaber
BIOS-type (Basic Input/Output System)
AMI
BIOS-egenskaber
UEFI BIOS, ASUS EZ Flash 3, ASUS UEFI BIOS EZ Mode
Sov/ Vågn
Aktivering af LAN (wake on LAN = WOL), vågn på PME
Hardware egenskaber
ASUS Q-Design, Q-DIMM, Q-Slot, CrashFree BIOS 3, ASUS DIGI+ VRM, Preboot eXecution Environment (PXE), ASUS Stainless Steel Back I/O, LANGuard, Lighting Control, overspændingsbeskyttelse, ASUS 5X Protection III, ASUS SafeSlot Core, DIY Friendly Design
