Varenummer: 3020826
Netgear MS510TXM-100EUS 8-Port Multi-Gigabit/10G Ethernet Smart Switch with 2 SFP+ Ports
Switch, L3 Lite, smart, 4 x 100/1000/2.5G + 4 x 1/2.5/5/10GBase-T + 2 x 10 Gigabit SFP+ (uplink), desktop, monterbar på stativ
4.535,00 kr.
3.628,00 kr. ekskl. moms
Billigste fragt (privatkunde) 33,00 kr.
Fjernlager, 3 dages levering
As a leading provider of network equipment for SMBs, NETGEAR understands the importance of providing a great choice of speed and power that can support the business's needs to keep up with the growth of network speed, virtualization, cloud-based services and applications like VoIP, video streaming and IP surveillance, whether in the hospitality, catering, education or retail domains. Also, the increase in speeds for Wi-Fi 6 Access Points now imply the need for faster speeds in the network.
The MS510TXM 8-Port Multi-gig/10G switches with 2 SFP+ Ports join the NETGEAR Standalone Smart Switches family, adding multi-gigabit/10G speed, a high PoE budget for all PoE/PoE+ devices, and Ultra60 PoE++ support for deploying devices with multi-gig capabilities and speed, such as Wi-Fi 6 Access Points (eg. WAX610 from NETGEAR), multi-gig or 10G NAS.
NETGEAR Smart Switches offer powerful Layer 2+/Lite L3 features, great PoE functionality, and enhanced performance and usability. They are purposely designed for modern applications and support BYOD which requires companies to have more bandwidth to ensure smooth network connectivity with no congestion. Furthermore, in 2.5G or 5G speeds, there is no requirement to upgrade your cabling from Cat5E, allowing for savings in installation costs.
To empower the Wireless and PoE applications, NETGEAR Insight Remote/ Cloud Management is added to these two new switch models as an optional management mode. By activating the NETGEAR Insight Cloud management, the users will enable management features allowing businesses simpler configuration and deployment from anywhere using the NETGEAR Insight app from mobile devices or the Insight Cloud Portal from any device with a web browser.
The MS510TXM 8-Port Multi-gig/10G switches with 2 SFP+ Ports join the NETGEAR Standalone Smart Switches family, adding multi-gigabit/10G speed, a high PoE budget for all PoE/PoE+ devices, and Ultra60 PoE++ support for deploying devices with multi-gig capabilities and speed, such as Wi-Fi 6 Access Points (eg. WAX610 from NETGEAR), multi-gig or 10G NAS.
NETGEAR Smart Switches offer powerful Layer 2+/Lite L3 features, great PoE functionality, and enhanced performance and usability. They are purposely designed for modern applications and support BYOD which requires companies to have more bandwidth to ensure smooth network connectivity with no congestion. Furthermore, in 2.5G or 5G speeds, there is no requirement to upgrade your cabling from Cat5E, allowing for savings in installation costs.
To empower the Wireless and PoE applications, NETGEAR Insight Remote/ Cloud Management is added to these two new switch models as an optional management mode. By activating the NETGEAR Insight Cloud management, the users will enable management features allowing businesses simpler configuration and deployment from anywhere using the NETGEAR Insight app from mobile devices or the Insight Cloud Portal from any device with a web browser.
Producent
Varenummer
3020826
Model
MS510TXM-100EUS
Ean
606449152364
Til producentens hjemmeside
Kontakt producent
Produktbeskrivelse
NETGEAR Smart MS510TXM - switch - 8 porte - smart - monterbar på stativ
Enhedstype
Switch - 8 porte - L3 Lite - smart
Pakningstype
Monterbar på stativ
Porte
4 x 100/1000/2.5G + 4 x 1/2.5/5/10GBase-T + 2 x 10 Gigabit SFP+ (uplink)
Præstation
Stof-gennemløb: 140 Gbps
Videresendelsesrate (64‑byte pakker): 14,8 Mpps
2,5 Gbps kobberlatens (64-byte pakker): 5.903 µs
2,5 Gbps kobberlatens (1518-byte pakker): 6.040 µs
2,5 Gbps kobberlatens (9216-byte pakker): 6.079 µs
10 Gbps kobberlatens (64-byte pakker): 2.420 µs
10 Gbps kobberlatens (1518-byte pakker): 2.501 µs
10 Gbps kobberlatens (9216-byte pakker): 2.499 µs
10 Gbps fiberlatens (64-byte pakker): 1.257 µs
10 Gbps fiberlatens (1518-byte pakker): 1.337 µs
10 Gbps fiberlatens (9216-byte pakker): 1.348 µs
Videresendelsesrate (64‑byte pakker): 14,8 Mpps
2,5 Gbps kobberlatens (64-byte pakker): 5.903 µs
2,5 Gbps kobberlatens (1518-byte pakker): 6.040 µs
2,5 Gbps kobberlatens (9216-byte pakker): 6.079 µs
10 Gbps kobberlatens (64-byte pakker): 2.420 µs
10 Gbps kobberlatens (1518-byte pakker): 2.501 µs
10 Gbps kobberlatens (9216-byte pakker): 2.499 µs
10 Gbps fiberlatens (64-byte pakker): 1.257 µs
10 Gbps fiberlatens (1518-byte pakker): 1.337 µs
10 Gbps fiberlatens (9216-byte pakker): 1.348 µs
Kapacitet
Pakkebufferstørrelse: 2 MB
ACL-indtastninger (indgang): 100
VLANs understøttet: 256
IGMP-grupper: 256
Prioritetskøer: 8
DHCP-opsnusningsindlæg: 256
ACL-indtastninger (indgang): 100
VLANs understøttet: 256
IGMP-grupper: 256
Prioritetskøer: 8
DHCP-opsnusningsindlæg: 256
MAC adresse table størrelse
32.000 optegnelser
Jumborammesupport
10KB
Routingprotokol
IGMP, STP, RSTP, MSTP, IGMPv2, IGMPv3, MLD, MLDv2
Protokol til fjernadministration
IPv6, SNMP 1, SNMP 2c, SNMP 3, HTTP, HTTPS, RADIUS, RSTP, RMON 1, RMON 2, RMON 3, RMON 9, TACACS+
Egenskaber
ACL support, 802.1x autentificering, Advanced QoS, DSCP support, DoS attack beskyttelse, IGMP-forespørger, IGMP snooping, udgangratebegrænsende, EEE, kabeltest, 2 blæsere, GVRP, Voice VLAN, LLDP support, LLDP-MED, LACP, sky-administreret, VoIP support, ZTP, DHCP snooping, beskyttede porte, løkkeforebyggelse, portspejling, dobbelt firmware-billeder, firmware kan opgraderes, gem og send, WRR, SP, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Unknown Storm Control, datatransport, fuld dupleksmodus, bloker ukendt multicast, DHCP klient, Guest VLAN, DiffServ understøttet, tilbageløkke-detektion, DNS-klient, BPDU, EAPOL, SNTP-understøttet, UDP, Syslog understøttet
Overensstemmelsesstandarder
IEEE 802.1x, IEEE 802.1p, IEEE 802.3az, IEEE 802.1ab (LLDP), IEEE 802.3ad (LACP), IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, UPnP
Dimensioner (B x D x H)
33 cm x 20.6 cm x 4.3 cm
Vægt
2.08 kg
Lokalisering
Europa
Generelt
Enhedstype
Switch - 8 porte - L3 Lite - smart
Pakningstype
Monterbar på stativ, desktop
Porte
4 x 100/1000/2.5G + 4 x 1/2.5/5/10GBase-T + 2 x 10 Gigabit SFP+ (uplink)
Præstation
Stof-gennemløb: 140 Gbps
Videresendelsesrate (64‑byte pakker): 14,8 Mpps
2,5 Gbps kobberlatens (64-byte pakker): 5.903 µs
2,5 Gbps kobberlatens (1518-byte pakker): 6.040 µs
2,5 Gbps kobberlatens (9216-byte pakker): 6.079 µs
10 Gbps kobberlatens (64-byte pakker): 2.420 µs
10 Gbps kobberlatens (1518-byte pakker): 2.501 µs
10 Gbps kobberlatens (9216-byte pakker): 2.499 µs
10 Gbps fiberlatens (64-byte pakker): 1.257 µs
10 Gbps fiberlatens (1518-byte pakker): 1.337 µs
10 Gbps fiberlatens (9216-byte pakker): 1.348 µs
Videresendelsesrate (64‑byte pakker): 14,8 Mpps
2,5 Gbps kobberlatens (64-byte pakker): 5.903 µs
2,5 Gbps kobberlatens (1518-byte pakker): 6.040 µs
2,5 Gbps kobberlatens (9216-byte pakker): 6.079 µs
10 Gbps kobberlatens (64-byte pakker): 2.420 µs
10 Gbps kobberlatens (1518-byte pakker): 2.501 µs
10 Gbps kobberlatens (9216-byte pakker): 2.499 µs
10 Gbps fiberlatens (64-byte pakker): 1.257 µs
10 Gbps fiberlatens (1518-byte pakker): 1.337 µs
10 Gbps fiberlatens (9216-byte pakker): 1.348 µs
Kapacitet
Pakkebufferstørrelse: 2 MB
ACL-indtastninger (indgang): 100
VLANs understøttet: 256
IGMP-grupper: 256
Prioritetskøer: 8
DHCP-opsnusningsindlæg: 256
ACL-indtastninger (indgang): 100
VLANs understøttet: 256
IGMP-grupper: 256
Prioritetskøer: 8
DHCP-opsnusningsindlæg: 256
MAC adresse table størrelse
32.000 optegnelser
Jumborammesupport
10KB
Routingprotokol
IGMP, STP, RSTP, MSTP, IGMPv2, IGMPv3, MLD, MLDv2
Protokol til fjernadministration
IPv6, SNMP 1, SNMP 2c, SNMP 3, HTTP, HTTPS, RADIUS, RSTP, RMON 1, RMON 2, RMON 3, RMON 9, TACACS+
Krypterings algoritme
TLS 1.2
Autentificeringsmetode
RADIUS, Extensible Authentication Protocol (EAP), TACACS+
Egenskaber
ACL support, 802.1x autentificering, Advanced QoS, DSCP support, DoS attack beskyttelse, IGMP-forespørger, IGMP snooping, udgangratebegrænsende, EEE, kabeltest, 2 blæsere, GVRP, Voice VLAN, LLDP support, LLDP-MED, LACP, sky-administreret, VoIP support, ZTP, DHCP snooping, beskyttede porte, løkkeforebyggelse, portspejling, dobbelt firmware-billeder, firmware kan opgraderes, gem og send, WRR, SP, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, Unknown Storm Control, datatransport, fuld dupleksmodus, bloker ukendt multicast, DHCP klient, Guest VLAN, DiffServ understøttet, tilbageløkke-detektion, DNS-klient, BPDU, EAPOL, SNTP-understøttet, UDP, Syslog understøttet
Overensstemmelsesstandarder
IEEE 802.1x, IEEE 802.1p, IEEE 802.3az, IEEE 802.1ab (LLDP), IEEE 802.3ad (LACP), IEEE 802.3x, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, UPnP
Processor
: 1 GHz
RAM
256 MB
Flashhukommelse
64 MB
Statusindikatorer
Strøm, blæser, link/aktivitet/hastighed
Ekspansion / Konnektivitet
Interface
4 x 100/1000/2.5G RJ-45
4 x 1/2.5/5/10GBase-T RJ-45
2 x 10GBase-X SFP+ uplink
4 x 1/2.5/5/10GBase-T RJ-45
2 x 10GBase-X SFP+ uplink
Effekt
Strømenhed
Intern strømforsyning
Antal installeret
1
Strømforbrug ved drift
47 watt
Diverse
Udstyr inkluderet
Gummifødder
Rackmonteringspakke
Inkluderet
MTBF (forventet tid mellem fejl)
1,059,519 timer
Lokalisering
Europa
Mål og vægt
Bredde
33 cm
Dybde
20.6 cm
Højde
4.3 cm
Vægt
2.08 kg
Miljømæssige parametre
Min. driftstemperatur
0 °C
Maks. driftstemperatur
50 °C
Fugtighedsgrad ved brug
90 % (ikke-kondenserende)
Min. lagertemperatur
-20 °C
Maks. Opbevaringstemperatur
70 °C
Lagerfugtighedsgrad
95 % (ikke-kondenserende)
